Hyundai i-30: Tire Pressure Monitoring System / Components and components location
Hyundai i30 (PD) 2018-2024 Service Manual / Suspension System (NON-ECS) / Tire Pressure Monitoring System / Components and components location
| Components |
| 1. Body control
module (BCM) 2. TPMS sensor (FL) 3. TPMS sensor (RL) |
4. TPMS sensor
(FR) 5. TPMS sensor (RR) |
Description and operation
Description
TREAD Lamp
–
Tire Under Inflation / Leak Warning.
1.
Turn on condition
–
When tire pressure is below allowed threshold
–
When rapid leak is detected by the sensor...
