Hyundai i-30: Rear Wiper/Washer / Components and components location
Hyundai i30 (PD) 2018-2025 Service Manual / Body Electrical System / Rear Wiper/Washer / Components and components location
| Component Location |
| 1. Rear wiper
arm & blade 2. Rear wiper arm nut 3. Rear wiper grommet |
4. Rear wiper
motor assembly 5. Rear wiper motor bolt |
Rear Wiper Motor
Repair procedures
Inspection
Rear Wiper Motor
1.
Remove the connector from the rear wiper motor.
2...
